► magnitude (RMS): 0.0015 dB to 0.0040 dB (typ.)► phase (RMS): 0.015° to 0.025° (typ.)
16001
R&S®ZNH8, 30 kHz to 8 GHz
R&S®ZNH18, 30 kHz to 18 GHz
R&S®ZNH26, 30 kHz to 26.5 GHz
Important facts
Specification
R&S®ZNH
Why this is important
Dynamic range
up to 100 dB (typ.)
This allows the instrument to accommodate large variations between the maximum and minimum power levels in a measurement.
Battery operating time
4 h
Long battery life means saves weight by eliminating the need for a spare battery in the field, while still having plenty of power for measurements.
Display
7" capacitive WVGA touchscreen with gesture support
Intuitive operation for faster measurement setup and configuration.
Span is set with pinch and zoom.
Receiver architecture
The four-receiver architecture consists of two reference receivers and two test receivers at both port 1 and port 2.
The R&S®ZNH can support more advanced calibration types such as unknown through, open, short and match (UOSM) calibration. Such calibration is useful for DUTs with different input or output connector types at the test ports.
Scope of delivery
Power cable
Quick start guide
3 year warranty
Recommended options/accessories
Description
Type
Calibration kit, type N (m), 50 Ω, 0 Hz to 18 GHz
R&S®ZN-Z170
Calibration kit, type N (f), 50 Ω, 0 Hz to 18 GHz
R&S®ZN-Z170
Calibration kit, 3.5 mm (m), 50 Ω, 0 Hz to 26.5 GHz
R&S®ZN-Z135
Calibration kit, 3.5 mm (f), 50 Ω, 0 Hz to 26.5 GHz
ZNH Handheld Vector Network Analyzer
Model overview
Model, frequency range
Number of ports
Basic functions
Dynamic range
Maximum port output power
Trace noise
Measurement points
R&S®ZNH4, 30 kHz to 4 GHz
2
DTF, one-port cable loss, VSWR, return loss, S₁₁, S₂₁, S₁₂, S₂₂ (magnitude and phase)
up to 100 dB (typ.)
up to 0 dBm (meas.) (300 kHz ≤ f ≤ 24 GHz)
► magnitude (RMS): 0.0015 dB to 0.0040 dB (typ.)► phase (RMS): 0.015° to 0.025° (typ.)
16001
R&S®ZNH8, 30 kHz to 8 GHz
R&S®ZNH18, 30 kHz to 18 GHz
R&S®ZNH26, 30 kHz to 26.5 GHz
Important facts
Specification
R&S®ZNH
Why this is important
Dynamic range
up to 100 dB (typ.)
This allows the instrument to accommodate large variations between the maximum and minimum power levels in a measurement.
Battery operating time
4 h
Long battery life means saves weight by eliminating the need for a spare battery in the field, while still having plenty of power for measurements.
Display
7" capacitive WVGA touchscreen with gesture support
Intuitive operation for faster measurement setup and configuration.
Span is set with pinch and zoom.
Receiver architecture
The four-receiver architecture consists of two reference receivers and two test receivers at both port 1 and port 2.
The R&S®ZNH can support more advanced calibration types such as unknown through, open, short and match (UOSM) calibration. Such calibration is useful for DUTs with different input or output connector types at the test ports.
Scope of delivery
Recommended options/accessories
Description
Type
Calibration kit, type N (m), 50 Ω, 0 Hz to 18 GHz
Calibration kit, type N (f), 50 Ω, 0 Hz to 18 GHz
R&S®ZN-Z170
Calibration kit, 3.5 mm (m), 50 Ω, 0 Hz to 26.5 GHz
R&S®ZN-Z135
R&S®ZN-Z135
Calibration kit, 50 Ω, 2 MHz to 4 GHz
R&S®ZN-Z103
Calibration kit, 50 Ω, 1 MHz to 6 GHz
R&S®ZN-Z103
Soft carrying bag
R&S®HA-Z220
Carrying holster
R&S®HA-Z322
