FSC Spectrum Analyzer
Model overview
Model
Frequency range
Preamplifier
Resolution bandwidth
Phase noise
Level measurement uncertainty
DANL
TOI
R&S®FSC3, model .03 (base)
9 kHz to 3 GHz
optional
10 Hz to 3 MHz
−95 dBc (1 Hz),−105 dBc (1 Hz) (typ.)
up to 1 dB,0.5 dB (typ.)
−161 dBm,−165 dBm (typ.)
> +10 dBm,+15 dBm (typ.)
R&S®FSC3, model .13 (tracking gen.)
up to 1.5 dB,0.5 dB (typ.)
R&S®FSC6, model .06 (base)
9 kHz to 6 GHz
−155 dBm,−159 dBm (typ.)
> +3 dBm,+10 dBm (typ.)
R&S®FSC6, model .16 (tracking generator)
up to 1.5 dB,1 dB (typ.)
Important facts
Specification
R&S®FSC
Why this is important
Tracking generator dynamic range
90 dB (typ.)
Provides higher dynamic range when performing filter measurements.
Lower phase noise enables greater signal detection accuracy close to the carrier.
30 kHz
up to −95 dBc (1 Hz)
100 kHz
up to −100 dBc (1 Hz)
1 MHz
up to −120 dBc (1 Hz)
Recommended options/accessories
Description
Type
Preamplifier for spectrum analyzer
R&S®FSC-B22
19" rackmount kit for two R&S®FSC
R&S®ZZA-T33
19" rackmount kit for one R&S®FSC
R&S®ZZA-T34
Headphones
R&S®FSH-Z36
Near-field probes, 30 MHz to 3 GHz
R&S®HZ-15
Preamplifier for R&S®HZ-15, 100 kHz to 3 GHz
R&S®HZ-16
