Power Meter
NRX Power Meter
Model overview
Model
Frequency range
Power measurement range
Measurement channels
Display
Compatible sensors
Weight
R&S®NRX
DC to 170 GHz (sensor-dependent)
0.1 fW to 30 W (average) (sensor-dependent)
1 to 4
5"/12.7 cm (touch) with 800 × 480 pixel resolution (WVGA)
▶ R&S®NRPxxS(N)/T(N)/A(N)/P series▶ R&S®NRP-Zxx series▶ R&S®NRQ6 frequency selective power sensor▶ R&S®NRT-Zxx directional power sensors
2.35 kg/2.58 kg (option-dependent)
Important facts
Specification
Why this is important
Large high-resolution touchscreen
TFT 5" 800 × 480 pixel
Intuitive and fast operation.
Number of measurement channels
Flexibility to meet current and future requirements.
Sensor compatibility
R&S®NRPxxS/N, R&S®NRPxxT/TN/TWG, R&S®NRPxxA/AN, R&S®NRP-Zxx, R&S®NRT-Zxx
One base unit for all current Rohde & Schwarz power sensors and selected discontinued sensors.
Automatic pulse analysis
with R&S®NRPxP sensors
Time-saving, no need for manual calculation.
Sensor check source
50 MHz/1 GHz, CW and pulse mode
High-precision sensor verification in a module.
Power reflection measurements
R&S®NRX-B9 option
First base unit compatible with termination and directional power sensors in a single device.
Scope of delivery
Recommended options/accessories
Description
Type
Base unit
Power meter
Hardware options
R&S®NRX-B1
Third (C) and fourth (D) sensor connector, for R&S®NRP
R&S®NRX-B4
IEEE-488 (GPIB) interface
R&S®NRX-B8
Sensor interface, for R&S®NRT
R&S®NRX-B9
Software options
Second measurement channel
R&S®NRX-K2
Third and fourth measurement channel
R&S®NRX-K4
Keysight emulation mode (N1911A/N1912A/N432A/E4418A/E4419A)
R&S®NRX-K301
Recommended extras for R&S®NRPxxS(N)/T(N)/A(N)/P power sensors
A minimum of one interface cable is required for power sensor operation.
8-pole interface cable, length: 1.50 m
R&S®NRP-ZK8
8-pole interface cable, length: 3.00 m
8-pole interface cable, length: 5.00 m
Recommended extras for R&S®NRX
19" rack adapter (for one R&S®NRX power meter and one empty casing)
R&S®ZZA-KNA22
19" rack adapter (for two R&S®NRX power meters)
R&S®ZZA-KNA24
