RWC5020M-64 Tester for LoRa® / LoRaWAN®
RWC5020M-64 LoRa®/LoRaWAN®용 테스터는 최대 64/96 채널을 제공하는 소형 올인원 테스터로,
LoRa® 및 LoRaWAN® 기술 테스트 및 측정을 위한 완벽한 솔루션을 제공합니다.
연구 개발(R&D), 품질 관리(QC) 및 제조업체에 완벽하게 적합합니다.
비신호 모드뿐만 아니라 활성화 절차와 같은 신호 모드에서 수행할 수 있는 다양한 테스트 기능을 제공합니다.
완전 자동화된 PC 소프트웨어는 LoRa Alliance®에서 지정한 사전 인증 테스트를 수행하여
사용자가 디바이스를 테스트하고 디버깅할 수 있도록 지원합니다.
■ LoRaWAN® COMPLIANCE
Confirming that the end device meets the functional requirements of the
LoRaWAN® protocol specification
RWC5020M pre-certification test is recommended for the purpose of pre-qualification.
Since RWC5020M supports 8/16/64/96 channels,
it can measure all the functions and performance of the
DUT without channel limitations depending on the region.
Supported Pre-certification Test Option
▶ LoRaWAN Specification 1.0.2:
- LoRaWAN® European EU 863-870MHz Region End Device Certification Requirements
- LoRaWAN® US + Canada 902-928MHz Region End Device Certification Requirements
- LoRaWAN® Asia AS 923MHz Region End Device Certification Requirements
- LoRaWAN® South Korea 920-923MHz Region End Device Certification Requirements
- LoRaWAN® India IN865-867MHz Region End Device Certification Requirements
▶ LoRaWAN Specification 1.0.4:
- LoRaWAN 1.0.4 End Device Certification Requirements for All Regions
- Supported Regions: EU863-870, US 902-928, AS923-1, AS923-2, AS923-3, AS923-4,
KR920-923, IN865-867,AU915-928, RU864-870, and EU433
▶ Supported LoRaWAN® Region
EU 868 // EU 433 // US 915 // AU 915 // CN 470 // KR 920 // AS 923 // IN 865 // RU 864
▶ Supported LoRaWAN® Protocol
- Compatible with LoRaWAN® version of V1.0.2, V1.0.3, V1.0.4 and V1.1.0
- Class A/B/C
- Application Layer Package Certification Test
- FUOTA test
■ LoRa® /LoRaWAN® TEST SOLUTIONS
▶ Protocol & Functional Test
- Support of LoRaWAN® Pre-Certification Tests for all regions
- Scenarios for transmission of MAC commands and user application data
- FUOTA Test with user firmware binaries
▶ RF Test Solutions
- RF Performance Tests for End-device – TX Power and RX Sensitivity
(downlink: RX1, RX2, RXC or Ping-slot)
- RF Performance Tests for Gateway – TX Power and RX Sensitivity (uplink)
- Semtech’s Non-regression Tests for Gateway – integrated
with RWC2020A Interference Generator
- LBT Test Solution for end-devices and gateways – integrated
with RWC2020A Interference Generator
▶ Manufacturing Test Solutions
- Signal Generator and Signal Analyzer
- Frequency Measurement Function
- Separate TX/RX Tests with DUT controls – power, frequency and sensitivity
- Simultaneous TX/RX Tests (MFG) without wired DUT controls
▶ PC Application Software
- Fully Automated for Execution of All Built-in Functions
- Measurement and Test Data Logging
- MAC and Application Protocol Messages Logging
