RWC5021P Tester for LoRa® / LoRaWAN®
RWC5021P LoRa®/LoRaWAN®용 테스터는 엔드 디바이스용 LoRaWAN® 프로토콜 분석을 위한
소형 동글형 테스터로, 사전 인증 테스트 기능과 신호 모드에서 수행할 수 있는 링크 분석기 기능을 제공합니다.
RWC5020x PC 어플리케이션 소프트웨어는 모든 지역에서 사용 가능한 LoRaWAN 프로토콜과의
호환성 검증을 위한 LoRaWAN 사전 인증 테스트 기능을 제공합니다.
■ LoRaWAN® COMPLIANCE
Confirming that the end device meets the functional requirements of the
LoRaWAN® protocol specification
RWC5021P pre-certification test is recommended for the purpose of pre-qualification.
Some of the test items could be limited or not fully covered due to the limitation of
maximum number of channels supported simultaneously.
Supported Pre-certification Test Option
▶ LoRaWAN Specification 1.0.2:
- LoRaWAN® European EU 863-870MHz Region End Device Certification Requirements
- LoRaWAN® US + Canada 902-928MHz Region End Device Certification Requirements
- LoRaWAN® Asia AS 923MHz Region End Device Certification Requirements
- LoRaWAN® South Korea 920-923MHz Region End Device Certification Requirements
- LoRaWAN® India IN865-867MHz Region End Device Certification Requirements
▶ LoRaWAN Specification 1.0.4:
- LoRaWAN 1.0.4 End Device Certification Requirements for All Regions
- Supported Regions: EU863-870, US 902-928, AS923-1, AS923-2, AS923-3,
AS923-4, KR920-923, IN865-867,AU915-928, RU864-870, and EU433
▶ Supported LoRaWAN® Region
EU 868 // EU 433 // US 915 // AU 915 // CN 470 // KR 920 // AS 923 // IN 865 // RU 864
▶ Supported LoRaWAN® Protocol
- Compatible with LoRaWAN® version of V1.0.2, V1.0.3, V1.0.4 and V1.1.0
- Class A/B/C
■ LoRa® /LoRaWAN® TEST SOLUTIONS
▶ Protocol & Functional Test
- Support of LoRaWAN® Pre-Certification Tests for all regions
- Scenarios for transmission of MAC commands and user application data
- FUOTA Test with user firmware binaries
▶ PC Application Software
- Fully Automated for Execution of All Built-in Functions
- MAC and Application Protocol Messages Logging
