HMF25xx Arbitrary Function Generator
Model overview
Model
Frequency range
Output voltage
Total harmonic distortion
Arbitrary waveform vertical resolution
Arbitrary waveform signal memory length
Interface
R&S®HMF2525
10 µHz to 25 MHz
5 mV to 10 V (peak-to-peak) (into 50 Ω)10 mV to 20 V (peak-to-peak) (open circuit)
0.04% (typ.) (f ≤ 100 kHz)
14 bit
up to 256 kpoints
dual-interface USB/RS-232, optional interfaces LAN/USB and IEEE-488 (GPIB)
R&S®HMF2550
10 µHz to 50 MHz
Important facts
Specification
R&S®HMF2525/R&S®HMF2550
Why this is important
Widest measurement range across all functions
R&S®HMF2525:
▶ sine: 10 µHz to 25 MHz
▶ square: 10 µHz to 25 MHz
▶ pulse: 100 µHz to 12.5 MHz
▶ ramp/triangle: 10 µHz to 5 MHz
▶ arbitrary: 100 µHz to 12.5 MHz
R&S®HMF2550:
▶ sine: 10 µHz to 50 MHz
▶ square: 10 µHz to 50 MHz
▶ pulse: 100 µHz to 25 MHz
▶ ramp/triangle: 10 µHz to 10 MHz
▶ arbitrary: 100 µHz to 25 MHz
Allows utilization of the function generator for more applications and use cases.
Crisp color display
3.5" color TFT QVGA
See crisp representation of the waveform and all parameters.
Scope of delivery
User manual
Power cord
3 year warranty
Recommended options/accessories
Description
Type
Options and system components
Dual Ethernet/USB interface
R&S®HO732
IEEE-488 (GPIB) interface
R&S®HO740
19" rackmount kit, 2 HU
R&S®HZ42
