ZVH Cable and Atenna Analyzer
Model overview
Model (frequency range)
Number of ports
Dynamic range
Port output power
Data points
Measurement mode (standard)
R&S®ZVH4 (100 kHz to 3.6 GHz)
2
100 dB
0 dBm to –40 dBm
101 to 1201
reflection, DTF, one-port cable loss
R&S®ZVH8 (100 kHz to 8 GHz)
Important facts
Specification
R&S®ZVH
Why this is important
Factory calibration available
●
Ensures accurate measurements even if the field technician forgets the calibration procedure.
Wizard support for common measurement functions
Increases repeatable field test patterns and reduces user errors.
Entry bandwidth
3.6 GHz
Determines lowest cost entry point into the family.
Preamplifier
included
Increases sensitivity for low signal level measurements.
Scope of delivery
Lithium-ion battery pack
LAN cable
USB cable
AC power supply
CD-ROM with software and documentation
Quick start guide
3 year warranty (one year for battery and accessories)
Recommended options/accessories
Description
Type
Options
Remote control via LAN or USB
R&S®ZVH-K40
Transmission measurement
R&S®ZVH-K39
Vector network analysis
R&S®ZVH-K42
Vector voltmeter
R&S®ZVH-K45
Spectrum analysis
R&S®ZVH-K1
Spectrogram measurement application
R&S®ZVH-K14
Power meter
R&S®ZVH-K9
Popular accessories
Combined open/short/50 Ω load calibration standard, DC to 8 GHz
R&S®FSH-Z28
Combined open/short/50 Ω load calibration standard, DC to 3.6 GHz
R&S®FSH-K29
Lithium-ion battery pack, 6.75 Ah
R&S®HA-Z206
Soft carrying bag
R&S®HA-Z220
Hard case
R&S®HA-Z321
GPS receiver
R&S®HA-Z240
