NPA Power Analyzer
Model overview
Model
GPIB
Bandwidth
Sampling rate
Resolution
Voltage input
Current input
Basic accuracy
Frequency accuracy
Input impedance
R&S®NPA101 power meter
–
DC to 100 kHz
500 ksample/s
simultaneous display of current and voltage, each with 16 bit
up to 600 V (RMS)
up to 20 A (RMS)
0.05% of reading
0.1% of reading
2 MΩ
R&S®NPA501 power analyzer
same as above
R&S®NPA501-G power analyzer
●
R&S®NPA701 compliance tester
R&S®NPA701-G compliance tester
Important facts
Specification
R&S®NPA
Why this is important
Configurable user interface and display
Fully configurable 3.5" QVGA color TFT display
Allows users to see the measurements. Also convenient for documentation and screenshot capture.
On-instrument policy testing
on-instrument IEC62301, EN50564, EN61000-3-2
Allows users to verify policies on the spot, without a PC and avoiding all associated IT and antivirus issues.
Broad set of advanced analysis
waveform mode, trend chart, inrush mode, harmonics view
Gain insight into user problems quickly and easily with integrated analysis tools that are quick and easy to use.
Scope of delivery
Quick start guide
Power cord
3 year warranty
Recommended options/accessories
Description
Type
Power meter, DC to 100 kHz
R&S®NPA101
Power analyzer, DC to 100 kHz
R&S®NPA501
Power analyzer, DC to 100 kHz, incl. IEEE-488 (GPIB) interface
R&S®NPA501-G
Compliance tester, DC to 100 kHz
R&S®NPA701
Compliance tester, DC to 100 kHz, incl. IEEE-488 (GPIB) interface
R&S®NPA701-G
Accessories
Mains adapter, EU version
R&S®NPA-Z1
Mains adapter, UK version
R&S®NPA-Z2
Mains adapter, US version
R&S®NPA-Z3
Mains adapter, CHN/AUS version
R&S®NPA-Z4
19" rack adapter, 2 HU, for one or two R&S®NPA power supplies
R&S®HZC95
