multistandard platform for automotive, broadcast, navigation and wireless applications with numerous digital standards
Since only one instrument is needed for a wide variety of applications, it has the flexibility for deployment at any time for other tasks on a production line. This minimizes potential unused capacity and allows a massive reduction of downtime on production lines.
Frequency range
4 kHz up to 7.125 GHz
To cover the DUT frequency range.
Phase noise
< −125 dBc
A generator with lower phase noise will add less unwanted noise to the DUT, revealing its true performance. Test the device, not the generator.
RF output power
up to +25 dBm
A higher power level allows a wider range of testing. Extra power enables the user to compensate for fixtures and cables between the generator and the test point, and removes the need for external amplifiers.
SMCV100B Vector Signal Generator
Model overview
Model
Frequency
RF output power
Phase noise
Display
R&S®SMCV100B
4 kHz to 3/6/7.125 GHz
up to +25 dBm
< −125 dBc (f = 1 GHz, 10 kHz offset)
5" touch display (800 × 480 pixel)
Important facts
Specification
R&S®SMCV100B
Why this is important
Multistandard platform
multistandard platform for automotive, broadcast, navigation and wireless applications with numerous digital standards
Since only one instrument is needed for a wide variety of applications, it has the flexibility for deployment at any time for other tasks on a production line. This minimizes potential unused capacity and allows a massive reduction of downtime on production lines.
Frequency range
4 kHz up to 7.125 GHz
To cover the DUT frequency range.
Phase noise
< −125 dBc
A generator with lower phase noise will add less unwanted noise to the DUT, revealing its true performance. Test the device, not the generator.
RF output power
up to +25 dBm
A higher power level allows a wider range of testing. Extra power enables the user to compensate for fixtures and cables between the generator and the test point, and removes the need for external amplifiers.
Scope of delivery
Recommended options/accessories
Frequency options
4 kHz to 3 GHz
R&S®SMCVB-B103
Frequency extension to 6 GHz
R&S®SMCVB-KB106
Frequency extension to 7.125 GHz
R&S®SMCVB-KB107
RF options
High output power
R&S®SMCVB-K31
Low phase noise
R&S®SMCVB-K709
Digital standards
5G NR Release 15
R&S®SMCVB-K444
5G NR Release 16
R&S®SMCVB-K448
5G NR Release 17
R&S®SMCVB-K471
5G NR Sidelink
R&S®SMCVB-K470
LTE Release 8
R&S®SMCVB-K255
LTE Release 9
R&S®SMCVB-K284
LTE Release 10
R&S®SMCVB-K285
LTE Release 11
R&S®SMCVB-K412
LTE Release 12
R&S®SMCVB-K413
LTE Release 13/14/15
R&S®SMCVB-K419
Cellular IoT Release 13
R&S®SMCVB-K415
Cellular IoT Release 14
R&S®SMCVB-K443
Cellular IoT Release 15
R&S®SMCVB-K446
3GPP FDD
R&S®SMCVB-K242
3GPP FDD HSPA/HSPA+, enhanced BS/MS tests
R&S®SMCVB-K283
GSM/EDGE
R&S®SMCVB-K240
EDGE Evolution
R&S®SMCVB-K241
