RTC1000 Oscilloscope
Model overview
Model
Bandwidth
Channel (analog/digital)
Consists of
Maximum sample rate
Maximum memory depth
R&S®RTC1002
50 MHz
2
R&S®RTC1000
R&S®RTC1K-72
70 MHz
R&S®RTC1000 + R&S®RTC-B220
R&S®RTC1K-102
100 MHz
R&S®RTC1000 + R&S®RTC-B221
2 Gsample/s
2 Msample
R&S®RTC1K-202
200 MHz
R&S®RTC1000 + R&S®RTC-B222
R&S®RTC1K-302
300 MHz
R&S®RTC1000 + R&S®RTC-B223
R&S®RTC1K-52M
2/8
R&S®RTC1000 + R&S®RTC-B1
R&S®RTC1K-72M
R&S®RTC1000 + R&S®RTC-B220 + R&S®RTC-B1
R&S®RTC1K-102M
R&S®RTC1000 + R&S®RTC-B221 + R&S®RTC-B1
R&S®RTC1K-202M
R&S®RTC1000 + R&S®RTC-B222 + R&S®RTC-B1
R&S®RTC1K-302M
R&S®RTC1000 + R&S®RTC-B223 + R&S®RTC-B1
Important facts
Specification
Why this is important
50 / 70 / 100 / 200 / 300 MHz (upgradeable, configurable)
Upgradeable bandwidth up to 300 MHz provides investment protection for future requirements.
Allows capture of the longest period of time at high sample rate.
Mixed signal option (MSO)
8 channels, upgradeable, 0.5 Gsample/s, 0.5 Msample
Ideal for analysis of digital buses and correlation with analog signals.
Multifunctional
DVM, counter, waveform generator, pattern generator, component tester
Saves desk space and is a smart investment.
Scope of delivery
Recommended options / accessories
Description
Type
Hardware options
Mixed signal upgrade for non-MSO models, 300 MHz
R&S®RTC-B1
Arbitrary waveform generator
R&S®RTC-B6
Software options
I²C/SPI serial triggering and decoding
R&S®RTC-K1
UART/RS-232/RS-422/RS-485 serial triggering and decoding
R&S®RTC-K2
CAN/LIN serial triggering and decoding
R&S®RTC-K3
Application bundle (R&S®RTC-K1, -K2, -K3, -B6)
R&S®RTC-PK1
Option bundle
Soft carrying bag
R&S®RTC-Z3
Rackmount kit
R&S®ZZA-RTC1K
